PW75

Wheel Excavator

Total Weight:

7500KG

Bucket Capacity:

0.3m³

Rated Power:

48Kw

  • Overall Dimensions (mm)
    6390*2175*2880
  • Engine Model
    YCF3065
  • Digging Power (kN)
    45
PW75 Wheel Excavator
PW75 Wheel Excavator

🔍 Details:PW75 Wheel Excavator

🚀 Superior Power & High Efficiency

✔ Powered by YCF3065 engine with 48KW/2200rpm rated power, strong output for heavy-duty working.

✔ 0.3m³ standard bucket capacity, 45KN max bucket digging force, high working efficiency.

✔ 24MPa hydraulic system pressure, stable and responsive for all working conditions.

✔ Low fuel consumption, 145L large fuel tank supports long-time continuous operation.

⚙️ Advanced Hydraulic & Travel System

✔ World-famous brand hydraulic components ensure stable performance and long service life.

✔ 4-wheel drive design, 0-30km/h travel speed, strong off-road performance.

✔ Full hydraulic steering, flexible and easy to operate in narrow working space.

✔ Cushioned cylinders reduce vibration, shock and noise, extend parts service life.

🛡️ Sturdy Structure & High Reliability

✔ Reinforced chassis and wheel reduction axles, high durability and stability.

✔ Integral welded boom with professional treatment, firm and crack-resistant.

✔ Wear-resistant steel bucket, thickened plates for heavy-duty construction work.

✔ 7500kg operating weight, balanced structure for stable digging and lifting.

📏 Excellent Working Range

✔ Max digging depth: 3900mm, max digging radius: 6300mm.

✔ Max digging height: 6380mm, max dumping height: 4700mm.

✔ 25° max climbing angle, strong adaptability to various terrains.

✔ Compact structure, small swing radius for urban and narrow construction sites.

🎛️ Comfortable Operation & Easy Maintenance

✔ Ergonomic control layout, comfortable operating experience for long hours work.

✔ Fully enclosed cab with wide view, air conditioner and heater available.

✔ Filters arranged at ground level, easy and quick maintenance and replacement.

✔ 110L hydraulic oil tank, reasonable design for low maintenance cost.

📊 PW75 Wheeled Excavator Technical Parameters

Performance Parameters
Bucket Capacity (m³) 0.3
Swing Speed (rpm) 0-12
Max. Climbing Angle (°) 25
Max. Bucket Digging Force (kN) 45
Max. Arm Digging Force (kN) 36
Engine Model YCF3065
Power/Speed (kW/rpm) 48/2200
Tire Model 8.25-16
System Pressure (MPa) 24
Operating Weight (kg) 7500
Ground Pressure (kPa) -
Working Range
Max. Digging Height (mm) 6380
Max. Dumping Height (mm) 4700
Max. Digging Depth (mm) 3900
Max. Vertical Digging Depth (mm) 2700
Max. Digging Radius (mm) 6300
Min. Swing Radius (mm) 2408
Max. Dozer Blade Ground Clearance (mm) 370
Max. Dozer Blade Cutting Depth (mm) 110
Overall Dimensions
Overall Dimensions L×W×H (mm) 6390 × 2175 × 2880
Cab Height (mm) 2880
Wheelbase (mm) 2400
Wheel Tread (mm) 1665
Min. Ground Clearance (mm) 260
Tail Swing Radius (mm) 2080
Travel System
Travel Speed (km/h) 0-30
Drive Type 4-Wheel Drive
Steering Type Full Hydraulic Steering
Fluid Capacities
Fuel Tank Capacity (L) 145
Hydraulic Oil Tank Capacity (L) 110
