SH200

🏗️ 21-Ton Crawler Excavator · Core Product Advantages

This 21-ton grade SH210 crawler excavator is fitted with 1m³ standard digging bucket, featuring outstanding digging power and high working efficiency. With stable overall performance and reliable quality, it is perfectly suitable for municipal engineering, earthmoving projects, quarry mining and various heavy construction works.

⚙️ Sufficient Power Output & Strong Environmental Adaptability

Adopting high-performance WP6 engine with rated power 129KW at 2200rpm, it delivers steady and sufficient power output. Matched with turbocharging technology, it can run stably under high altitude, low temperature and other harsh complex environments, fully meeting the demands of long-time high-intensity continuous construction operation.

⛏️ Powerful Digging Capacity & High Construction Efficiency

Equipped with max bucket digging force 140KN and arm digging force 99KN, supported by 32MPa stable system pressure, it possesses excellent soil cutting and rock breaking ability. The slewing speed reaches 11-13rpm with smooth and coherent whole machine actions, greatly improving daily construction output and working progress.

💧 Mature Hydraulic System for Precise & Smooth Operation

Main pump, main valve, swing motor and other core hydraulic parts adopt world famous brand accessories for stable quality. It applies advanced dual-pump confluence technology to increase oil supply flow for boom, arm and bucket, realizing faster response speed. Smooth swing start and stop ensures accurate positioning, effectively reducing working vibration and impact wear.

📏 Super Wide Working Range & Multi-scene Application

It has max digging radius 9850mm, max digging depth 6480mm, max digging height 9410mm and max dumping height 6730mm, covering comprehensive working space. The machine can easily finish deep foundation excavation, high position material unloading, site leveling and other different construction tasks.

🛠️ Reinforced Durable Structure & Long Service Life

The main boom adopts integral welding forming process, equipped with precision boring and shot peening reinforcement treatment to enhance overall structural strength. Forged design is used for arm connecting joints to realize uniform stress dispersion. The digging bucket is made of thickened wear-resistant steel plate, adapting to long-term heavy load working conditions and lowering failure rate effectively.

🛋️ Humanized Cabin Design for Comfort & Safety

The enclosed driving cabin owns broad vision with fewer blind working areas. All operating handles are arranged in ergonomic layout with light and flexible operation feel. Equipped with high-strength tempered glass, sun visor, integrated heating and cooling air conditioner and comfortable shock-absorbing seat, it relieves driver fatigue during long working hours and improves overall construction safety.

🧠 Intelligent Control System, Energy Saving & Low Noise

Built-in electronic throttle control and automatic idle speed function, the engine will automatically enter idle state after 5 seconds without operation, which obviously cuts down fuel consumption and working noise. Large color LCD monitor can real-time display engine speed, water temperature, oil pressure and other core data, making machine running status clear at a glance.

All maintenance filters are placed at ground accessible position for quick inspection and replacement. Large volume fuel tank and built-in spacious toolbox support long-distance and long-time continuous construction. Adopting high-quality matched components, it prolongs maintenance cycle, reduces construction downtime and lowers later comprehensive operation cost.

📋 Overview of Basic Equipment Parameters

This excavator reaches max climbing angle 30°, overall dimension 9590×2980×3185mm, tail swing radius 2880mm and min ground clearance 470mm, featuring great trafficability and strong site adaptability to fit various complex construction sites.
